Zebra ZT230

Model

Zebra’s most affordable industrial printers, the ZT200™ Series, incorporate extensive customer feedback and the learnings from legacy printers—creating innovative printers with a space-saving design. Featuring Zebra’s Link-OS® environment, the ZT200 Series provides users with effortless setup, intuitive operation and easy service and maintenance.

Print :

Connectivity :

Option :

Resolution :

Data sheet
Download

Print Technology	Direct Thermal or Thermal Transfer
Dimensions	32 mm x 241 mm x 279 mm (L x l x H)
Weight	20 lbs.
Warranty	1 Year, printhead 6 months
Resolution	203 dpi / 8 dots per mm 300 dpi / 12 dots per mm (optional)
Connectivity	Série + USB ou Série + Paralèlle + USB ou Série + USB + Ethernet ou Série + USB + Wireless
Media Characteristics	Lenght 203 dpi: 157"/3988 mm * 300 dpi: 73"/1854 mm - Width 0.75"/19.4 mm to 4.50"/114 mm- Maximum roll size : 8.0"/203 mm O.D. on a 3.0"/76 mm I.D. core * 6.0"/152 mm O.D. on a 1.0"/25 mm I.D. core - Thickness : 0.003"/0.076 mm to 0.010"/0.25 mm
Maximum Print Speed	6"/152 mm per second
